this example shows how to optimize using the particleswarm solver.

the objective function in this example is de jong’s fifth function, which is available when you run this example.

dejong5fcn

this function has 25 local minima.

try to find the minimum of the function using the default particleswarm settings.

fun = @dejong5fcn;
nvars = 2;
rng default % for reproducibility
[x,fval,exitflag] = particleswarm(fun,nvars)

optimization ended: relative change in the objective value
over the last options.maxstalliterations iterations is less than options.functiontolerance.

x = 1×2
  -31.9521  -16.0176

fval = 5.9288

exitflag = 1

is the solution x the global optimum? it is unclear at this point. looking at the function plot shows that the function has local minima for components in the range [-50,50]. so restricting the range of the variables to [-50,50] helps the solver locate a global minimum.

lb = [-50;-50];
ub = -lb;
[x,fval,exitflag] = particleswarm(fun,nvars,lb,ub)

optimization ended: relative change in the objective value
over the last options.maxstalliterations iterations is less than options.functiontolerance.

x = 1×2
  -16.0079  -31.9697

fval = 1.9920

exitflag = 1

this looks promising: the new solution has lower fval than the previous one. but is x truly a global solution? try minimizing again with more particles, to better search the region.

options = optimoptions('particleswarm','swarmsize',100);
[x,fval,exitflag] = particleswarm(fun,nvars,lb,ub,options)

optimization ended: relative change in the objective value
over the last options.maxstalliterations iterations is less than options.functiontolerance.

x = 1×2
  -31.9781  -31.9784

fval = 0.9980

exitflag = 1

this looks even more promising. but is this answer a global solution, and how accurate is it? rerun the solver with a hybrid function. particleswarm calls the hybrid function after particleswarm finishes its iterations.

options.hybridfcn = @fmincon;
[x,fval,exitflag] = particleswarm(fun,nvars,lb,ub,options)

optimization ended: relative change in the objective value
over the last options.maxstalliterations iterations is less than options.functiontolerance.

x = 1×2
  -31.9783  -31.9784

fval = 0.9980

exitflag = 1

particleswarm found essentially the same solution as before. this gives you some confidence that particleswarm reports a local minimum and that the final x is the global solution.
